TRIUMPH TR6
PLATE EC
STARTER MOTORS, LUCAS MODEL
M418G, 1969 UP TO 1971
V2-13
STARTER MOTORS, LUCAS MODEL M418G, 1969 UP TO 1971
STARTER MOTOR,
Lucas Model M418G; Lucas part nos.
1
25626A and 25626B; 12 volts, clockwise rotation; fitted up
to comm. nos. CC63895 and CP53637
STARTER MOTOR,
factory rebuilt unit, for the application
1
described in the previous listing
Please Note:
There is some indication in the Lucas records that
Model 35G-1 starter motors with remote solenoids were fitted to
some TR6's in early 1969. The Triumph records indicate that
this plan was cancelled prior to production. If a car is
encountered with a Model 35G-1 starter motor and remote
solenoid, these details are fully covered in our TR250 parts
catalogue, or you may ask a salesperson for assistance.
LU54240709
Field Coil Set
1
LU54240322
Armature
1
COMMUTATOR END DETAILS
LU54240300
BRACKET ASSEMBLY,
commutator end
1
Bush,
bearing, commutator end
1
Spring Set,
brush tension
1
Brushes Set
1
LU54140202
Washer,
thrust, steel, commutator end
1
Washer,
fabric, steel, commutator end
1
DRIVE END DETAILS
LU54242823
Bracket,
drive end
1
Bush,
bearing, drive end
1
LU54244559
Grommet,
bracket fixing
1
LU54240327
STARTER DRIVE PINION ASSEMBLY
1
Bush,
bearing, pinion
1
LU54259624
Plate,
operating lever
1
LU291013
Ring,
retaining plate
1
LU54250549
Washer,
thrust, drive end
1
LU54245339
DRIVE RETENTION KIT
1
517469
Collar,
thrust
1
517470
Jump Ring
1
ENGAGING LEVER DETAILS
LU54240960
Lever,
pinion engaging
1
LU54240485
Bolt,
pivot, lever
1
LU272549
Nut,
securing bolt
1
MISCELLANEOUS DETAILS
LU256009
Bolt,
through fixing
2
LU54240319
COVER BAND ASSEMBLY
1
LU54257851
Screw,
securing cover band
1
LU169160
Nut,
securing cover band
1
LU271731
Sundry Parts Kit
1
Plate No.
Part No.
Description
No. Off
STARTER MOTOR
--Continued
SOLENOID
1
LU60600678
END CAP AND CONTACTS KIT
1
LU54642810
Spring,
return, plunger
1
HARDWARE KIT,
securing starter motor to rear engine plate
1
and gearbox flange
Bolt
2
Washer,
shakeproof
2
Washer,
lock
2
Nut,
hex
2
Plate No.
Part No.
Description
No. Off
