PLATE EF
FRONT SIGNAL LAMPS
V2-16
FRONT SIGNAL LAMPS
FRONT PARKING/SIGNAL LAMPS,
U.S.A. models only,
1
up to comm. no. CF1
FRONT PARKING/SIGNAL LAMP ASSEMBLY,
L.H.
1
517822
Body,
rubber, L.H.
1
BASE,
lamp, L.H.
NSS
Bulbholder,
interior
1
Sleeve,
terminal
1
Bulb
1
LENS ASSEMBLY,
amber parking/amber signal, with
1
chromed edge, L.H., with screws
Screw,
securing lens
2
FRONT PARKING/SIGNAL LAMP ASSEMBLY,
R.H.
1
517820
Body,
rubber, R.H.
1
BASE,
lamp, R.H.
NSS
Bulbholder,
interior
1
Sleeve,
terminal
1
Bulb
1
LENS ASSEMBLY,
amber parking/amber signal, with
1
chromed edge, R.H., with screws
Screw,
securing lens
2
HARDWARE,
securing front parking/signal lamps to front
valance
Washer,
shakeproof
4
Nut,
hex
4
FRONT PARKING/SIGNAL LAMPS,
U.S.A. models only,
from comm. no. CF1 up to CF27000
1
FRONT PARKING/SIGNAL LAMP ASSEMBLY,
L.H.
1
517822
Body,
rubber, L.H.
1
BASE,
lamp, L.H.
NSS
Bulbholder,
interior
1
Sleeve,
terminal
1
Bulb
1
LENS ASSEMBLY,
amber parking/amber signal,
1
without chromed edge, L.H., with screws
Screw,
securing lens
2
FRONT PARKING/SIGNAL LAMP ASSEMBLY,
R.H.
1
517820
Body,
rubber, R.H.
1
BASE,
lamp, R.H.
NSS
Bulbholder,
interior
1
Sleeve,
terminal
1
Bulb
1
LENS ASSEMBLY,
amber parking/amber signal,
1
without chromed edge, R.H., with screws
Screw,
securing lens
2
HARDWARE,
securing front parking/signal lamps to front
valance
Washer,
shakeproof
4
Nut,
hex
4
FRONT PARKING/SIGNAL LAMPS,
U.S.A. models only,
from comm. no. CF27000 up to CF50000
FRONT PARKING/SIGNAL LAMP ASSEMBLY;
2
fits L.H. or R.H.
BASE,
lamp
NSS
Bulbholder,
interior, signal lamp
2
Bulbholder,
interior, parking lamp
2
Gasket,
lamp base
2
515061
Grommet,
cable entry, signal lamp
2
515060
Grommet,
cable entry, parking lamp
2
Bulb,
signal lamp
2
Bulb,
parking lamp
2
LENS,
amber signal/clear parking, with gasket
2
Gasket,
between lens and lamp base
2
SLP150
Divider,
lens
2
RIM,
lamp, with screws
2
SLP149
Screw,
securing rims and lenses to lamps
4
Plate No.
Part No.
Description
No. Off
FRONT PARKING/SIGNAL LAMPS
--Continued,
U.S.A. models only, from comm. no. CF27000 up to CF50000
MOUNTING KIT,
front parking/signal lamps to front bumper
1
Plinth,
mounting, L.H.
1
Plinth,
mounting, R.H.
1
HARDWARE,
securing mounting plinths to front
bumper
Screw,
set
4
Washer,
plain
4
Washer,
lock
4
Nut,
hex
4
HARDWARE,
securing lamps to mounting plinths
Washer,
plain
6
Washer,
lock
6
Nut,
hex
6
FRONT SIGNAL LAMPS
FRONT PARKING/SIGNAL LAMPS,
U.S.A. models
only, after comm. no. CF50000
FRONT PARKING/SIGNAL LAMP ASSEMBLY;
2
fits L.H. or R.H.
BASE,
lamp
NSS
Bulbholder,
interior, signal lamp
2
Bulbholder,
interior, parking lamp
2
Gasket,
lamp base
2
515061
Grommet,
cable entry, signal lamp
2
515060
Grommet,
cable entry, parking lamp
2
Bulb,
signal lamp
2
Bulb,
parking lamp
2
LENS,
amber signal/amber parking, with gasket
2
Gasket,
between lens and lamp base
2
SLP150
Divider,
lens
2
RIM,
lamp, with screws
2
SLP149
Screw,
securing rims and lenses to lamps
4
MOUNTING KIT,
front parking/signal lamps
1
Plinth,
mounting, L.H.
1
Plinth,
mounting, R.H.
1
HARDWARE,
securing mounting plinths to front bumper
Screw,
set
4
Washer,
plain
4
Washer,
lock
4
Nut,
hex
4
HARDWARE,
securing lamps to mounting plinths
Washer,
plain
6
Washer,
lock
6
Nut,
hex
6
MISCELLANEOUS COMPONENTS
Tubing,
black plastic, protecting lamp cables, thirty-six
A/R
inch length
Grommet,
small, between lamp cables and holes in
2
front valance panel, U.S.A. models only,
after comm. no. CF27000
Plate No.
Part No.
Description
No. Off
|
|
