TRIUMPH TR6
PLATE EY
WIRING HARNESSES
V2-36
WIRING HARNESSES
MAIN WIRING HARNESSES,
U.S.A. models
Main Harness,
fitted up to comm. no. CC50000
1
Main Harness,
fitted from comm. no. CC50000 up
1
to CC75000
Main Harness,
fitted from comm. no. CC75000 up to CF1
1
Main Harness,
fitted from comm. no. CF1 up to CF990
1
Main Harness,
fitted from comm. no. CF991 (late
1
1973) up to CF12500
Main Harness,
fitted from comm. no. CF12500 up to CF?
1
Main Harness,
fitted from comm. no. CF? (late 1974)
1
up to CF35000
Main Harness,
fitted from comm. no. CF35000 up to
1
CF50000
Main Harness,
fitted after comm. no. CF50000
1
MAIN WIRING HARNESSES,
models with L.H. steering
other than U.S.A.
309795
Main Harness,
fitted up to comm. no. CP50000
1
311311
Main Harness,
fitted from comm. no. CP50000 up to
1
CP75000
312369
Main Harness,
fitted from comm. no. CP75000 up to CR1
1
313179
Main Harness,
fitted from comm. no. CR1 up to CR5000
1
RKC572
Main Harness,
fitted after comm. no. CR5000
1
MAIN WIRING HARNESSES,
all models with R.H. steering
308796
Main Harness,
fitted up to comm. no. CP50000
1
311310
Main Harness,
fitted from comm. no. CP50000 up to CR1
1
313180
Main Harness,
fitted from comm. no. CR1 up to CR5000
1
RKC571
Main Harness,
fitted after comm. no. CR5000
1
BODY WIRING HARNESSES,
U.S.A. models
Body Harness,
fitted up to comm. no. CC75000
1
Body Harness,
fitted from comm. no. CC75000 up to CF1
1
Body Harness,
fitted from comm. no. CF1 up to
1
CF12500
Body Harness,
fitted from comm. no. CF12500 up to
1
CF50000
Body Harness,
fitted after comm. no. CF50000
1
BODY WIRING HARNESSES,
all models other than U.S.A.
215413
Body Harness,
fitted up to comm. no. CR1
1
218949
Body Harness,
fitted after comm. no. CR1
1
Plate No.
Part No.
Description
No. Off
CONNECTOR BLOCK,
connecting leads from alternator to
1
starter solenoid leads; fitted up to CC75000
GEARBOX WIRING HARNESSES,
back-up lamps,
U.S.A. models
Gearbox Harness,
back-up lamps, fitted up to
1
comm. no. CC75000
158338
Gearbox Harness,
back-up lamps and seat-belt
1
interlock, fitted from comm. no. CC75000 up to
CF50000
Gearbox Harness,
back-up lamps, fitted after comm.
1
no. CF50000
GEARBOX WIRING HARNESSES,
back-up lamps,
all models other than U.S.A.
Gearbox Harness,
back-up lamps, fitted up to
1
comm. no. CP75000
141037
Gearbox Harness,
back-up lamps, fitted after
1
comm. no. CP75000
OVERDRIVE WIRING HARNESSES,
A-type overdrive
Wiring Harness,
upper part, connecting switch and
1
relay to lower harness
Wiring Harness,
lower part, connecting upper harness
1
to interrupter switches and to solenoid
OVERDRIVE WIRING HARNESSES,
J-type overdrive
Wiring Harness,
upper part, connecting switch to lower
1
harness
Wiring Harness,
lower part, connecting upper harness
1
to interrupter switch and to solenoid
HEADLAMP WIRING
Cable and S.A.E. Connector Assembly,
headlamps
2
Sleeve,
plastic, protecting headlamp cables
2
LOW-TENSION LEADS,
from coil to distributor
Low-Tension Lead,
with two female connectors, fitted
1
up to comm. no. CF1 on carb models
Low-Tension Lead,
with two female connectors;
1
probably fitted to all P.I. models
Low-Tension Lead,
with one female connector and one
1
male connector, fitted after comm. no. CF1 on
carb models
Plate No.
Part No.
Description
No. Off
